OBDSTAR DC706 ECU/TCU Clone Tool – Professional ECU Cloning Solution
OBDSTAR DC706 ECU/TCU Clone Tool – Professional ECU Cloning Solution
1/2

OBDSTAR DC706 ECU/TCU Clone Tool – Professional ECU Cloning Solution Available in Lahore, Islamabad & across Pakistan

The OBDSTAR DC706 ECU/TCU Clone Tool is a genuine ECU programming tool for professional workshops and technicians. Buy the OBDSTAR DC706 ECU/TCU Clone Tool in Lahore from AM Auto Tools with 1 year warranty and setup support, delivered to Islamabad, Rawalpindi, Karachi and across Pakistan.


-11%Rs 410,000
Was: Rs 460,000You save Rs 50,000

About this item

  • ECU Clone (All by OBD, BENCH, BOOT, BDM & JTAG )
  • Engine ECU (ECM) Clone for Cars
  • Engine ECU (ECM) Clone for Motorcycles
  • Transmission Control Module (TCM) Clone
  • Body Control Module (BCM/Body ECU) Clone
  • Battery Management System (BMS) Clone
  • Vehicle Control Unit (VCU) Clone
  • Supports 2,050+ ECU types
  • Some advanced functions require the P003 Adapter
  • Supports 510+ TCM types
  • Volkswagen DQ-Series TCM Mileage Calibration
  • Delphi MT05 / MT05.2 / MT05.3 Motorcycle ECU Clone
  • BRP ME17.8.5 Motorcycle ECU Clone (Requires P003 Adapter)
  • Piaggio MIU G4 (M4G1) Engine ECU Clone
  • Full ECU Clone via OBD, Bench, Boot, BDM & JTAG
  • Automatic ECU Recognition
  • Strong Technical Help Database
  • Continuous Software Updates with New Functions
  • ECU clone (OBD, Bench, Boot on supported models)
  • Read/Write EEPROM, P-Flash, D-Flash, MAP
  • ECU Virgin (Reset)
  • ECU Recovery
  • Read IMMO PIN (supported ECUs)
  • Some Body ECU and Airbag module read/write
  • Supports many Toyota Denso ECUs when used with the correct adapters (P002/MP001/P003 depending on the ECU). ( obdstar.com )
  • Denso and Keihin/Honda supported ECUs
  • ECU cloning
  • EEPROM and Flash read/write
  • Bench and Boot mode operations
  • Automatic ECU identification
  • Intelligent search by ECU part number and MCU type. ( obdstar.com )
  • Denso ECU cloning
  • Bench read/write
  • EEPROM and Flash operations
  • Example: Suzuki HA112700 ECM Bench Read/Write is officially demonstrated by OBDSTAR. ( obdstar.com )
  • EFI ECU clone
  • EEPROM/Flash read-write
  • Supported motorcycle ECU functions vary by ECU model. ( obdstar.com )
  • Update the DC706 to the latest software.
  • Open ECU Flasher .
  • Select ECM → Car (or Motorcycle ).
  • Choose the manufacturer (Toyota, Honda, or Suzuki).
  • Select the vehicle or search by ECU Part Number .
  • Follow the built-in wiring diagram for OBD, Bench, Boot, or JTAG.
  • Read the original ECU data.
  • Write the data to the replacement ECU and perform cloning if supported. ( blog.eobdtool.co.uk )
  • Support depends on the ECU hardware number , not just the vehicle model.
  • Some Toyota, Honda, and Suzuki ECUs require the P003 or MP001 adapter for Bench/Boot operations.
  • Before starting a job, use the built-in Guide and Pinout pages or check the latest coverage list to confirm that your exact ECU is supported. ( obdstar.com )
  • Vehicle (e.g., Toyota Hilux 2022)
  • Engine
  • ECU part number (e.g., 89661-xxxxx or 33920-xxxxx)
  • Whether the DC706 supports it,
  • Which mode to use (OBD, Bench, Boot, or JTAG),
  • Which adapter is required,
  • And provide the correct connection method.

Technical details

ModelOBDSTAR DC706 ECU/TCU Clone Tool – Professional ECU Cloning Solution
CategoryECU Chip Tuning Programmer
Warranty1 year

Compare with similar items

OBDSTAR DC706 ECU/TCU Clone Tool – Professional ECU Cloning SolutionThis item
OBDSTAR ECU Master Configuration ( C ) package for HD Truck & Tractor ECM TCM BCM CloneOBDSTAR ECU MASTER PC-based ECU flasher CAR 12-VOLTS PACKAGEToyota Lexus ECU Flasher orignal
PriceRs 410,000Rs 460,000Rs 380,000Rs 185,000
Customer rating★★★★★★★★★★ 0★★★★★★★★★★ 0★★★★★★★★★★ 0★★★★★★★★★★ 0
Reviews0000
Part number———ECTP-019
Warranty1 year1 year1 year1 year

About the OBDSTAR DC706 ECU/TCU Clone Tool

DC706 ECU/TCU Clone Tool – Professional ECU Cloning Solution

If you need the OBDSTAR DC706 ECU/TCU Clone Tool in Lahore, our team can confirm it suits your vehicles and work before you buy.

Key Functions

The DC706 supports 7 professional cloning configurations :

Supported ECU Manufacturers

Supported Vehicle Brands

Cars

Motorcycles

Advanced Functions

Coverage

Engine ECU (ECM)

Transmission (TCM)

Body Modules

Supports 180+ Body Control Modules , including:

Special Functions

Software Interface

The DC706 software includes:

Toyota

The DC706 mainly supports Denso ECUs , including:

Honda

Supported functions include:

Suzuki

For Suzuki cars and motorcycles, DC706 supports:

Suzuki Cars

Suzuki Motorcycles

Typical Workflow

Important Notes

If you're an auto locksmith or ECU repair shop, tell me the exact:

Package Highlights

✔ Supports OBD, Bench, Boot, BDM & JTAG Modes

✔ 2,050+ Engine ECUs Supported

✔ 510+ Transmission Modules Supported

✔ 180+ Body Control Modules Supported

✔ Car & Motorcycle ECU Cloning

✔ ECU Recovery & Virgin Functions

✔ EEPROM / D-Flash / P-Flash Read & Write

✔ Mileage Calibration (Supported Models)

✔ Automatic ECU Identification

✔ Professional Technical Support Files

✔ Regular Software Expansion & Updates

Related tools

You may also want to compare it with the OBDSTAR ECU MASTER or the original Toyota ECU flasher.
